Kyoritsu Digital Multimeters Multitesters 1011

Kyoritsu Digital Multimeters Multi testers 1011

100% ORIGINAL

100% BRAND NEW

Temperature measurement, selectable for ºC and ºF

6040 counts with Bar Graph display

MIN/MAX function enables to record min & max value

REL(relative value) function to indicate the measurement variation

DC V    600.0mV/6.000/60.00/600.0/600V

(Input Impedance: 10MΩ, 100MΩ only 600mV) ±0.5%±2dgt (600.0mV/6.000/60.00/600.0V) ±0.8%±3dgt (600V)

AC V    6.000/60.00/600.0/600V

(Input Impedance: 10MΩ) ±1.0%±3dgt

(6.000/60.00/600.0V)±1.5%±3dgt (600V)

DC A    600/6000µA/60/600mA/6/10A ±1.2%±3dgt (600/6000µA/60/600mA) ±2.0%±5dgt (6/10A)

AC A    600/6000µA/60/600mA/6/10A ±1.5%±4dgt (600/6000µA/60/600mA) ±2.2%±5dgt (6/10A)

Ω    600Ω/6/60/600kΩ/6/60MΩ ±1.0%±2dgt

(600Ω/6/60/600kΩ/6MΩ) ±2.0%±3dgt (60MΩ)

Continuity buzzer    0 - 600Ω (Buzzer sounds below 100Ω)

Diode test    2.8V Release Voltage: Approx. 0.4mA Test Current

Capacitance    40/400nF/4/40/400/4000µF

Frequency    10/100/1000Hz/10/100/1000kHz/10MHz

DUTY    0.1 - 99.9% (Pulse width/Pulse period) ±2.0%±2dgt (- 10kHz)

Temperature    -50 - 300ºC (-58 - 572ºF)

(with the use of Temperature probe 8216)

Note: KEW 1011 can measure max. 700ºC

In order to measure over 300ºC, please use a K-type temperature probe available in the market.

Applicable standards    IEC 61010-1 CAT III 300V Pollution degree 2

IEC 61010-1 CAT II 600V Pollution degree 2

IEC 61010-031

IEC 61326

Display    6040 Counts

Power source    R6 (1.5V) × 2 (Auto-power-OFF within 15 minutes)

Dimensions    161(L) × 82(W) × 50(D)mm

Weight    Approx. 280g

Included Accessories

7066A (Test leads)

8216 (K-type Temperature probe)

0.8A/600V (Ceramic Fuse) × 1built-in

10A/600V (Ceramic Fuse) × 1built-in

R6 × 2

Instruction Manual
