3306P-1-502 Trimmer 5K Round Trimpot Trimming Potentiometer Single Turn 5 Kohm Through Hole 1 Turns

100% Brand New

100% High Quality

Electrical Characteristics :

Standard Resistance : 1k or 1KOhm

Resistance Tolerance  : ±25 % std.

Absolute Minimum Resistance : 2 % max. (≤2K = 30 ohms)

Contact Resistance Variation . : 3 % max.

Resolution : Essentially infinite

Adjustment Angle : 215 ° nom.

Features :

>      6 mm Round / Single-Turn / Cermet

      Industrial / Open Frame

>      Cross slot adjustment options

>      Horizontal and vertical mounting styles

>      Dust resistant/splash resistant covers

>      PC board stand-offs and retention feature

>      Front and top adjust styles
