BAG Electronic Ballast BCS35.2FX-11 220-240 replaces BCS35.2FX-01 BCS Primus T5

BAG Electronic Ballast BCS35.2FX-11 220-240 replaces BCS35.2FX-01 BCS Primus T5

100% BRAND NEW

100% GOOD QUALITY

BAG Electronic Ballast

BCS35.2FX-11 220-240

replaces BCS35.2FX-01

BCS Primus T5

Dimensions:280 x 30 x 21 [mm]

Lamp - T5 FH 35W - 21W - 14W

Short housing in flat design for space-saving application in luminaires

Multipower - Technology for operation with different lamps on the same control gear

Energy controlled, electrode preserving lamp warm start for maximum lamp life irrespective of switching frequency; starting time < 1,5 s

Cut-Off technology: minimized heat current through electrodes during operation, for optimum light output and reduced power loss.

Safety switch-off in case of abnormal lamp operation, e. g. defective electrode and end of lamp life; tested acc. to EN 61347-2-3 + Test 2

Flimmer free light through high frequency lamp operation, no stroboscope effect

Constant lamp output independent of mains voltage fluctuations

Optimum ignition safety even at low temperatures: automatic second start if necessary

Automatic restart after lamp replacement

Suitable for direct current operation and emergency lighting installations; complies with requirements for emergency lighting according to EN 61347- 2-3/J

Quick restart of lamps after short power disruptions

Connecting earth can be disregarded in suitable luminaires with safety classification 2

Energy efficiency EEI= A2BAT
